Why is my Hunter sprinkler not receiving power?

There is no AC power present (the controller is not receiving power). Check to see if the transformer is properly installed. The display reads “SENSOR OFF”. The rain sensor is interrupting irrigation or the sensor jumper is not installed.

How to bypass rain sensor on Hunter sprinkler system?

Slide the Rain Sensor switch on front panel to the BYPASS position to bypass rain sensor circuit, or install the sensor jumper. Rain sensor will not shut off system. Incompatible rain sensor or the jumper was not removed when sensor was installed. Manual Single Station Mode Used. Make sure sensor is micro-switch type such as Mini-Clik®.

Which is the best irrigation controller for home use?

Since 2001, the Pro-C has been the contractor’s choice in residential irrigation control. The Pro-C has proven to be the most reliable and robust controller in the industry, with the flexibility to expand on demand due to its modular design.

What does err stand for on Hunter sprinkler system?

The display reads a station number and ERR, such as “2 ERR”. Short in valve wiring circuit, or faulty solenoid on the station number indicated. Check wire circuit or solenoid for the valve number indicated. repair short or replace solenoid. Press any button to clear the “ERR” from the display.

How to troubleshoot a Hunter Pro C sprinkler system?

Check AC power wiring. Correct any errors. Make sure slide bar is in “Power On” position. Install 9v battery inside panel, if still no display replace Pro-C panel. The display reads “SP ERR”. Electrical noise is entering the system.

The display reads a station number and ERR, such as “2 ERR”. Short in valve wiring circuit, or faulty solenoid on the station number indicated. Check wire circuit or solenoid for the valve number indicated. repair short or replace solenoid. Press any button to clear the “ERR” from the display.

What are the common problems with sprinkler controllers?

4 Common Problems with Sprinkler Controllers and How to Fix Them 1. The blank display More than likely, your unit has experienced some kind of electrical service disruption that has… 2. The inactive controller If the system doesn’t seem to be running, check that the controller is set to auto or

Where do I find shielded cable for Hunter sprinkler system?

Check the SmartPort® wiring harness. Verify that the red wire is attached to the AC1 terminal, the white wire to the AC2 terminal and the blue wire to the REM terminal. If the wires were extended then they will need to be replaced with shielded cable. Contact your local distributor for information on shielded cable. The display reads “P ERR”.
