The standard NM cable used for interior residential wiring inside walls and floor and ceiling cavities is known as NM-B. This cable is approved for use in dry locations only; you will never see it used in outdoor locations or buried beneath the ground.

What use is NM cable suitable for?

NM Building Cable Standard NM cable is suitable for interior residential wiring, within ceiling cavities or walls and it is known as NM-8. This type of cable cannot be used in outdoor locations or buried underground. It is approved for use only in dry areas.

Can I use NM cable in a commercial building?

NM cables are permitted to be installed in a Type V commercial building (for example), only if it is concealed in a stud/ceiling space (or any other space) with min 1/2″ sheetrock or other finish material with equivalent 15-minute fire rating.

Where can type NM cable not be used?

• In any dwelling or structure not specifically permitted in 334.10(1), (2), (3), and (5)
• Exposed within a dropped or suspended ceiling cavity in other than one- and two-family and multifamily dwellings.
• As service-entrance cable.

Can NM cable be used outside?

Under the 2008 code, you must use UF cable anytime NM-style cable (even in conduit) exits the side of the house. That is, you are no longer allowed to put NM-B cable in watertight conduit outside of the house in wet locations.

Can you put Romex in conduit?

Yes, NM cable can be in conduit. In fact. NEC calls for it to be in conduit, when protection from physical damage is required.

Can I use Romex in an apartment building?

National Electrical Code – NEC (also know as NFPA 70) Section 334.10 NEC 2002 allows Type NM cable in any building that can be built of combustible construction as defined by the building code.

At what intervals does nm need to be secured?

NM cable must be supported and secured every 4 ½ ft. and within 12 inches of every outlet box, junction box, cabinet, or fitting.

Can you run Romex above a suspended ceiling?

C: NM cable is permitted to be run exposed in dropped or suspended ceilings in multifamily dwellings. Lighting above a suspended ceiling in a business office of type II construction can be wired with NM cable.

What is the difference between NM and NMC cable?

Type NM cable is defined as insulated conductors enclosed within an overall nonmetallic jacket, while Type NMC is insulated conductors enclosed within an overall corrosion-resistant nonmetallic jacket. The only difference between the two definitions is that NMC is corrosion-resistant and NM cable is not.

Article first time published on

Why is Romex illegal?

Staffers there said house wiring known by the brand name Romex can be dangerous if the insulation is gnawed by rodents or punctured by nails. They said the flexible insulation on the cable lacks the protection of conduit, the rigid metal tubes that encase wires.

Can I use Romex in the garage?

The National Electrical Code has identified Romex as an underground feeder. Romex electrical wiring has at least two non-metallic sheath conductors under the sheath. Again, due to its flame-resistant, moist-resistant coating, Romex electrical wiring can be used in the basement, garage, or cooler spaces.

Is Romex allowed in commercial construction?

Type NM, Type NMC, and Type NMS cables shall be permitted to be used in the following: … No type NM, NMC, or NMS, or non-metallic sheathed cable (Romex) usage in commercial applications regardless of mixed-use occupancy.

Is it OK to use Romex outside?

Romex is a type of electrical wire used in various applications. … Romex wires cannot be used outdoors because, if it gets wet with water, gas, oil or another solvent, these liquids could penetrate the jacket and ruin the connection by getting in contact with the bare copper ground wire.

Is NM cable waterproof?

NEC Section 334.10(A)(1) specifically permits NM Cable in both exposed and concealed work in normally dry locations it’s actually Section 334.12(B)(4) that states NM Cable is not permitted in Wet or Damp location.

Can you use Romex in damp locations?

“Romex” (NM) does not belong in conduit, and it is not allowed for use in damp/wet locations.

Can you use Romex in condos?

Metal conduit isn’t required just because you have metal studs. There are plastic bushings me that you can put in the metal studs that you can run Romex. However, local codes may require the use of conduit and condos and other multiunit buildings.

What does AC cable stand for?

Electrical current flows from a point of positive charge to a point of negative charge whilst essentially the electrons flow in the opposite direction. AC stands for an alternating current. Essentially the polarity of the supply is changing with time and as it does the current flows in one direction and then the other.

Can NM cable be exposed?

Section 336-6 permits NM cable to be installed in exposed locations and has permitted this installation technique since the introduction of NM cable into the Code in the 1930s. If installed exposed, the cable must closely follow the building surface or be installed on running boards.

What is nm wire?

Sometimes known as “Romex,” named for one of the common brand names, NM cable is a flexible electrical cable that features an outer plastic sheathing that protects two or more insulated conductors, as well as a bare copper ground wire. …

Can you run Romex in cabinets?

The National Electrical Code requires that plastic-sheathed cable (commonly called Romex) be protected in areas where it’s subject to abuse. … If you can run the plastic-sheathed cable high in the cabinets or behind drawers, you may not need conduit.

Can you use Romex in walls?

Running electrical wires running through finished walls is almost always done with a sheathed cable, often known as NM (non metallic) cable, or Romex (named after one of the popular brands). … For a 15-amp circuit, 14-gauge wire is the standard, while for a 20-amp circuit, 12-gauge wire is the norm.

Where can Romex be exposed?

A non-compliant installation due to all the exposed Romex wiring. Romex is a brand name of non-metal sheathing wire. To give you an overview of what the National Electrical Code (NEC) regulations state, Romex wire shouldn’t be left exposed anywhere in the house, be it the basement, attic, or the home itself.

Can you use Romex in metal boxes?

Metal boxes can also be used with Romex or NM wiring if desired, though special precautions must be taken to ensure proper grounding. … Even if the device does not complete the ground, Romex or NM wiring can always be used with metal electrical boxes by attaching the bare or green grounding wire to the box by a screw.

How often should Romex be stapled?

General Cable Support Runs of NM cable must be supported at least every 54 inches. 1 They also must be secured within 12 inches of an electrical box that includes a cable clamp or within eight inches of a box or enclosure without a cable clamp.

Can you put two wires one staple?

You are allowed to put 2 lines under 1 staple. The conductors can cross the gas line or run next to it but not secured to the gas line.

How far does Romex need to be supported?

Article 336-18 stated that cable must be secured in place at intervals not exceeding 4.5 feet (1.37 m) and within 12 inches (305 mm) from every cabinet, box, or fitting.

Is Romex NM or NMC?

Romex™ is a common type of residential wiring that is categorized by the National Electrical Code (NEC) as underground feeder (UF) or non-metallic sheathed cable (NM and NMC). … Unlike other cables commonly found in homes, they are permitted in damp environments, such as basements.

What NM cable is used in wet locations?

For wet or damp locations, UF-B (underground feeder) cable is designated as acceptable for damp locations, such as when burying it directly in the earth. UF cable sheaths the individual conductors in solid, water-proof plastic vinyl, making it fully moisture-proof.

What does type NM-B mean?

Type NM-B (Non-Metallic Sheathed Cable) is commonly used for residential wiring of luminaries, devices and appliances. Type NM-B ampacity limitation shall be in accordance with the 60ºC conductor temperature rating, as specified in the NEC.

Why is Romex so expensive 2021?

These price increases are due to factors such as China’s economic recovery from the pandemic, sustainable green energy stimuluses, and supply disruptions.
