Plumbing codes require that trap primers be provided for “emergency” floor drains and other traps subject to evaporation. An example of an “emergency” floor drain is one in a toilet room.

Where do you put trap primer?

The trap primer valve should be installed vertically at least twelve (12) inches [305mm] above the grid of a floor drain, or the flood rim of the equipment which the trap is to serve.

What is a trap primer used for?

The ASSE Standard is referenced in Plumbing Codes. Trap Primers are designed primarily to supply water to floor drain traps which have infrequent use and in which water evaporation would allow sewer gas to enter the premises. This method of priming traps uses a potable water supply to the trap primer device.

Do I need a trap seal primer?

Trap seal primers are a necessity where floor drains are infrequently used and in areas such as mechanical and service rooms. In surprisingly little time, evaporation of water in floor drain traps will allow sewer gas to enter the interior of the building.

Do all fixtures need a trap?

Because of its shape, the trap retains some water after the fixture’s use. This water creates an air seal that prevents sewer gas from passing from the drain pipes back into the building. Essentially all plumbing fixtures including sinks, bathtubs, and showers must be equipped with either an internal or external trap.

How many traps can a trap primer serve?

Singular electronic trap primers can be used to prime 1, or up to, 4 floor drain traps with optional distribution unit. Electronic Trap Primers deliver a timed discharge of water to the floor drain P-traps to ensure the traps maintain a water seal.

Does a floor sink need a trap primer?

All plumbing fixtures, including floor drains, are required to have traps. … For a water-supply-fed type trap primer, this happens automatically, based upon a water pressure drop when there is flow within the potable water piping system, such as using a sink faucet, flushing a toilet, etc.

Do basement floor drains have traps?

The floor drain is considered a sanitary fixture. That means it functions just like a toilet or sink or shower. It has a trap inside of it just as those items do, and it holds water to seal away any foul odors trying to get into your basement.

What is a trap seal primer outlet?

A trap primer (or trap seal primer) is a plumbing device or valve that adds water to traps. … The trap primer mitigates this problem by injecting water, either directly or indirectly, into the trap to maintain the water seal indefinitely.

How do I keep my P-trap from drying out?

P-traps can dry out as quickly as a month, sometimes even less than that. This happens most often in winter. To prevent your P-trap from drying out, run the sink or shower for a minute or two once a week to keep water flowing and your P-traps from drying out.

Article first time published on

How do you use a trap primer?

Trap Primer Valves To adjust: Turn adjusting screw counter clockwise until a steady flow is produced. Turn adjusting screw clockwise until dripping just stops. Primer is now set to line pressure. Cycle primer at least (5) times to insure proper activity.

How much does a trap primer cost?

This item PPP PR-500 Prime-rite Primer Automatic Trap Primer ValvePPP P1-500 P-1 Primer Automatic Trap Primer ValveCustomer Rating4.3 out of 5 stars (25)4.1 out of 5 stars (4)Price$4088$6288Sold ByPlumber’s ParadisePlumber’s ParadiseMeasurement Systemmetric, inchinch

How much water does a trap primer use?

A water-supplied trap primer typically uses 4-8 ounces of water at a time. Some models are adjustable. After adding evaporation and multiplying the number of drains in a commercial building, the water use can quickly turn from ounces to many gallons per hour.

Are house traps required?

House traps are required here according to State & Local Code, they are generally inside the house and used to access the main line leaving the house for snaking purposes. There should be a fresh air vent connected upstream of the trap.

Are running traps legal?

Full “S” traps, bell traps, drum traps, crown-vented traps, and running traps are prohibited. … (5) Trap seal. Each “P” trap shall have a water seal of not less than 2 inches and not more than 4 inches and shall be set true to its seal.

Do drains need a trap?

Yes, shower and tub drains require a trap in the plumbing to prevent harmful sewer gases from coming into the home.

Are floor drains vented?

Pipe Size (inches)Maximum Discharge from Upper Fixture Drain (dfu)2 1/2 to 36

How does a waterless trap seal work?

Often employing a type of flexible self-sealing membrane, waterless traps open during use and allow waste water to flow through the fitting, but close once the waste water drains through the fitting. This self-sealing action allows water to flow, whilst preventing foul sewer gases from entering the building.

Why are Bell traps prohibited?

The problem with these traps is that they are prone to clogging, and they are less sanitary than the modern P trap. Bell traps were used for floor drains. They also are prone to clogging and are less sanitary. These traps are a reportable deficiency in newer homes.

How far below drain should P trap be?

However, the Universal Plumbing Code stipulates that the total developed length of all tailpieces, arms and fittings connecting the drain to the p-trap must be 24 inches or less. Jennifer Roberts has enjoyed writing since 2008.

How do you attach trap seal primer?

If using trap seal primer, insert connection tube into primer adapter. Otherwise, remove adapter. Apply thread seal tape to threads of primer plug and screw in plug to seal the outlet.

What is the hole in the basement floor for?

1 Answer. It’s a floor drain. It was covered in an attempt to keep sewer gas from coming out of it once the trap dries up. If you’re going to cover it, it should be an airtight seal.

Does a basement floor drain need a vent?

The floor drain trap will need it’s own vent, though once you are above floor level with the vent, you may make horizontal runs and tie into other vent pipes provided the sizing is appropriate. Some codes allow a mechanical venting device, which obviates the need to run the vent outside somehow.

Why does my P-trap not hold water?

Dry p-traps occur when the trap or interceptor has lost its water seal, allowing sewer gases to build back up through the drain and into your home. Leaky p-traps can start as something small and turn into something much bigger if the leak isn’t fixed right away. … Clogged p-traps are the product of a slow-running drain.

Why does my P-trap smell?

A p trap is designed to use water to block the sewer gases from leaking up the drain. If a sink’s p trap dies out this can result in a drain that smells bad. To alleviate this problem pour water down the drain to restore the water barrier in the p trap.

Why does sewer smell come and go?

One of the most common causes of sewage smells is a clogged drain. When your home’s wastewater has nowhere to go, the odors will come back up the drain they should be going down.

What is the lowest point in the trap?

The structurally lowest point in a trap that can retain hydrocarbon is referred to as spill point.

What are trap seals?

The trap seal is a device with a one-way valve that allows water to flow down the drain but forms a seal that stops air from escaping up from the drain. A trap seal is much easier to install and maintain, and there is no worry about fixture use, fixture type, or water pressure.

Can trap primers be installed horizontally?

Install in a frequently used horizontal cold water line above the trap to be protected. The trap primer valve should be installed vertically at least twelve (12) inches above the grid of a floor drain, or the flood rim of the equipment which the trap is to serve.

Where is the trap in my house?

The easiest way to find the sewer trap is to locate the fresh air inlet pipe which is typically located near the front wall of your house. On the outside front or side of your house it will be exposed and covered by a grating.

What is a sewer trap plug?

A plug or cap for a house trap is around a $10.00 item that if worn or not installed properly can allow sewer gases and foul water to escape into a house.
