The feeler arm is the sensor inside the ice maker that stops it from making too much ice. It alerts the ice maker when the ice tray is full. If the feeler arm is stuck, it won’t be able to adjust itself according to the ice level in the tray. This will make the ice maker think that the tray is full when it isn’t.

Where is feeler arm on Whirlpool ice maker?

The feeler arm is the metal wire that stops the icemaker when the ice-bin gets full. Sometimes this feeler arm will jump out of the hole on the back of the head of the icemaker so that it will lift up and back down when the icemaker cycles. If it is out of the hole, place it back and your problem should be fixed.

What is an icemaker feeler arm?

The feeler arm is the wire arm that shuts the icemaker down then it hits the ice. There is a spring inside the icemaker head that will force the arm back down after the motor lifts it up. If this spring is broken the arm will not come back down to push the switch as if it were hitting ice, shutting the icemaker off.

Should ice maker feeler arm be up or down?

To turn ON the icemaker, lower the feeler arm to the ON (down) position. To turn OFF the icemaker, raise the feeler arm to the STOP (up) position.

What position should the ice maker ARM be in?

Ice maker control arms should flip up and down easily. If the ice maker control arm, connecting rod, or shut-off arm is broken or not installed properly, ice production may stop, or the ice bin may overflow as the ice maker continues to produce ice after the ice bin is already full.

How do I know if ice maker is working?

1. If the icemaker mold is empty, you can manually pour about 4 ounces of water in the icemaker mold.
2. Wait about 2 hours.
3. If the icemaker has dropped ice cubes out from the mold, you know the icemaker itself is working.

Does the bar go up or down to make ice?

If the wire arm of your ice maker is in the up position, this signifies to the ice maker that the ice storage bucket is full and turns the ice maker off. If you would like your ice maker to continue making ice, the arm lever should be in the down position.

How do I reset my ice maker?

Turn The Ice Maker Off and On Again This is a simple matter of resetting the power to your ice maker. By flipping the switch off and back on, you may be able to reset the functionality so that your ice maker begins to dispense ice again.

Why would my ice maker stop making ice?

Cause: A common cause for a clog is frozen water in the line. … Cause: There is also a possibility that the water filter for the ice maker is clogged. Fix: Locate and replace the water filter. Filters for ice makers are typically located inside the refrigerator (to keep them from freezing).

Is there a reset button on Whirlpool ice maker?

Press the on/off Switch If you can’t find the reset button nor the feeler arm, you can try pressing the on/off switch. This switch should also reset the ice maker and should get it working again properly. … Underneath the ice tray and cover plate. (For some Whirlpool ice maker models you have to remove both)

Article first time published on

How do I force my ice maker to cycle?

If your gear has a small notch in it, then you may need a flat-head screwdriver. Use it to turn your gear counterclockwise until you hear the mentioned click. In both situations, the click that is heard will force the ice maker to cycle.

Why is my Whirlpool freezer not making ice?

In other instances, your a Whirlpool ice maker not making ice may be due to insufficient water supply. A clogged water filter, kinked water line hose, or defective water inlet valve can restrict the water flowing to an ice maker. When this happens, ice production will be limited or completely stop.

How do you manually run an ice maker?

To manually start a cycle, either grasp the ejector and rotate upward (CW fr. front), or use a screwdriver to turn the smaller gear (CCW) if yours has a slot for this. Once you turn it a short distance, you’ll hear a little ‘click and the unit will start to run.

Why is my Whirlpool ice maker slow?

The top reasons for a slow ice maker inside of a freezer are incorrect temperature setting, too much or too little food inside, and a clogged water line or filter.

How do you troubleshoot an ice maker?

1. Check the shutoff arm.
2. Check the supply valve.
3. Inspect the water supply line.
4. Test the shutoff switch.
5. Check the freezer temperature.
6. Inspect the ejector gear.
7. Test the ejector motor.
8. Test the ice mold heater.

Will unplugging my fridge reset the ice maker?

Leave the refrigerator unplugged for 5 minutes. This will allow the ice system to reset. After 5 minutes, replug the refrigerator and turn the switch back on. This should cause the ice maker to start working again.

How long does it take a whirlpool ice maker to make ice?

It will take 6 to 12 hours for the fridge-freezer’s ice maker to make ice after you have installed it. The first three batches of ice cubes should be thrown away to make sure all the ice cubes you use are made from clean water.

How do you manually cycle a whirlpool ice maker?

Look at the center of the Whirlpool icemaker to find the rotating arm that pushes the ice cubes out. Grab the plastic teeth on the arm, and gently pull them in a clockwise direction. You will hear a slight winding sound. The icemaker should start into its cycle.

Why is the red light flashing on my Whirlpool ice maker?

Open the freezer door and observe the red status light next to the ice maker’s on/off switch. Result: … The red status light should be steady on. If the light continues to flash, your optics are either blocked in some way or they need to be replaced.

How do you unfreeze a whirlpool ice maker?

Apply heat with a hairdryer to the ice maker fill tube, which is usually a white, rubber-like hose. Hold the nozzle of the hairdryer at the front of the ice maker so that the heat will blast into the fill line. Set the hairdryer to its lowest heat setting to avoid melting the plastic lines and parts of the ice maker.

How often does a whirlpool ice maker cycle?

Under those proper conditions, most ice maker cycles will produce about 8-10 full cubes (depending on the size of your tray) at a time. This cycle will repeat every 90 – 180 minutes until the ice tray is full, which can typically hold 4-11 lbs of ice.
