In a fluorescent lighting system, the ballast regulates the current to the lamps and provides sufficient voltage to start the lamps. Without a ballast to limit its current, a fluorescent lamp connected directly to a high voltage power source would rapidly and uncontrollably increase its current draw.

Is ballast the same as sand and gravel?

Contains particles of various sizes ranging from 20mm down to a fine sand. It is mainly used for concreting by adding cement, and can often be termed as ‘sand and gravel’, ‘ballast’, ‘aggregate’, ‘all-in’, ‘three-quarter down with sand’ or ’20mm down with sand’.

What are the two types of ballast?

There are two lamp families that work with a ballast: fluorescent and HID. And there are two types of ballasts in each family: magnetic and electronic. Magnetic ballasts are the older ballast technology. For the fluorescent family, both T12 linear fluorescents and two-pin CFLs use magnetic ballasts.

What is the difference between ballast and aggregate?

Increases strength of concrete – ballast is a heavier aggregate than other concrete mix materials, such as sand. This means that ballast can provide a stronger bond in the mix as ballast is heavier and rougher, which improves the bond of the paste.

Do you add cement to ballast?

Mixing 1 part cement to 6 parts ballast creates concrete suitable for driveways, paths and patios, and increasing the ratio to 1:8 gives foundation-strength concrete. It is of course possible to add other materials to increase the strength of the concrete – these often include steel reinforcing bars (“rebar”).

Can I use ballast as sub base?

Can I use ballast as a sub base? Ballast is available in different types for different needs. 0-20mm ballast is perfect for sub-base and concrete foundations. 20mm screened ballast is versatile and can be used on driveways, footpaths, oversite fill as well as sub-bases.

Can you lay paving slabs on ballast?

How to lay a Garden Patio using Decorative Concrete Slabs or Natural Stone Paving. … This can be done be using a Ballast and Cement mix (6 parts Ballast to 1 part Cement with just enough water to form a semi dry mix) or Type 1 compacted with a ‘wacker plate’ which can be hired from your local plant hire company.

Can you use sharp sand instead of ballast?

If I ask for ballast they will give 1/2 scoop of each 20mm gravel and sharp sand. So yes. Ive done all sorts with this mix from fence posts, footings etc.

Can I use gravel as sub base?

If your builder uses the gravel he may find it will dissipate too easily into the ground and will spend more time and money to get the levels needed. I would not advise using the gravel. A well constructed base means your drive will never get sink holes.

What happens if you use wrong ballast?

If you use a wrong sized ballast the LRC will not be tuned so you are likely to not start the lamp at all. There is the possibility of burning out components pre-maturely also due to overcurrent and overvoltage conditions particularly if using a larger ballast on a smaller fixture.

Article first time published on

Can I use any ballast?

When considering a ballast for your lamp, make sure they have corresponding ANSI (American National Standards Institute) codes. Matching ANSI codes guarantees that the ballast you chose can be used with your lamp. However, ballasts are often compatible with more than one lamp, and vice versa.

Can you use LED bulbs with a ballast?

No LED bulbs require a ballast, although some are engineered to work with an existing ballast. You will find ballast-compatible or “plug-and-play” LEDs that are designed to replace linear fluorescents, compact fluorescents, or HIDs.

What is electromagnetic ballast?

Electromagnetic Ballast (Magnetic Ballast) LIGHTING: A ballast used with discharge lamps that consists primarily of transformer-like copper windings on a steel or iron core.

How does ballast work?

In a fluorescent lighting system, the ballast regulates the current to the lamps and provides sufficient voltage to start the lamps. … Once the arc is established, the ballast quickly reduces the voltage and regulates the electric current to produce a steady light output.

Which is the best material to be used as ballast?

Among above materials, broken stone from Igneous rocks like quartzite and granite forms the excellent ballast materials. When these are not available then lime stone and sand stone can also be used as good ballast material.

What is the strongest concrete mix ratio?

Strong Concrete Mix Ratio In making concrete strong, these ingredients should usually be mixed in a ratio of 1:2:3:0.5 to achieve maximum strength. That is 1 part cement, 2 parts sand, 3 parts gravel, and 0.5 part water.

How many bags of cement do I need for 1 ton of ballast?

Regarding this, “1 ton ballast how much cement?”, generally there are 6 bags of 25kg (total 150kg) of Portland cement to 1 ton of ballast by using mix of one part cement to 6 part ballast, for 1:5 mix, generally there are 7 bags of cement to a ton of ballast and for 1:4 mix there are 9 bags of cement are required.

How many shovels of ballast do I need for a bag of cement?

1 bag cement (6 shovels) + 3 bags of ballast will just about fit in – it may overflow slightly.

How thick should mortar be under slabs?

Add a mortar bed The mortar should be damp, not runny. Spread it out and level it with a trowel. The mortar bed needs to be 30-40mm thick and should enable the slabs, when positioned, to sit 6-10mm high.

Can I use ballast as a sub base for a shed?

A standard concrete mix ratio of 1 part cement to 5 parts ballast (aggregate and sand) is usually perfectly adequate for shed bases but you can add reinforcing fibres if you are housing anything particularly heavy.

Is ballast OK for patio base?

Ballast, gravel and hardcore MOT Type 1 (hardcore) is crushed carboniferous limestone, used to create a hardcore base under patios, paving, driveways and artificial grass. It can also be used as a filling product.

What is mot roadstone?

Bulk Bag MOT Type 1 Roadstone MOT Type 1 is a crushed aggregate material used to provide a stable sub-base for road surfaces and pathways. Both primary and recycled material can be used to produce a Type 1 sub-base.

What is mot ballast?

MOT is crushed carboniferous limestone, and is used to create a hardcore base under patios, paving, driveways and artificial grass. MOT can also be used as a filling product.

Can I use old slabs as sub-base?

It will be fine.

Can I use concrete as a sub-base?

Any potential ‘soft-spots’ in the subgrade can allow the concrete to sink from the center or turn up from the edges. Owing to its inflexibility, the concrete slabs can crack. As concrete is highly compressed and heavy, it may crack under its own weight if not provided a suitable sub-base.

Can you lay slabs without a sub-base?

Some paving types, block paving for example, nearly always need a sub-base, while others, such as pattern imprinted concrete, may not need one, but wouldn’t be any less effective if one was to be included. … You should only exclude a sub-base if there is good reason to do so.

Can I make concrete with just sand and cement?

Can I make concrete with just sand and cement? No, you can’t make concrete with only sand and cement. Concrete isn’t considered concrete without aggregates like gravel and stone. It’s the aggregates that contribute to concrete having high strength.

What size ballast is best for concrete?

The right amounts of ballast or sand-aggregate can also be expressed in simple ratios. So for the concrete mix mentioned above, your cement: sand: aggregate ratio should be 1:2:4 or ballast to cement ratio of 6 to 1. For a low-grade concrete with 10MPa strength, the perfect ratio should be 1:3:6.

Can I make concrete with just sharp sand?

Having a larger grain size than other types of sand means sharp sand is slightly heavier. Typically, sharp sand is used within applications where more strength and less flexibility is required. For example, it is ideal for mixing concrete and is commonly used for floor screeds and laying paving courses.

How many volts does a ballast put out?

Fluorescent lamps use a ballast which transforms line voltage to a voltage to start up and operate the lamp(s). Newer fluorescent ballasts are usually rated for both 120 volts and 277 volts. Some are rated for only 120 volts, others for only 277 volts (used in commercial environments).

How many watts do ballasts use?

Electronic Ballasts Standard ballasts consist of a core and coil assembly. On a typical fixture with two 4 foot 40 watt T-12 fluorescent lamps, the ballast consumes about 13 to 16 watts of electricity. Thus the total consumption of the two lamps plus the ballast is about 93 to 96 watts.
