What are the default settings for DIP switches?

Figure shows the default settings for the DIP switches. Switch SW1-1 (SW1, switch 1) is set to the ON position. All other switches are set to the OFF position. Set the SW1 switches for the address of the dome drive. The following information is required to set the dome drive address: P-Type Control Default address is 2.

Where are the DIP switches on a spectra dome?

The DIP switches used to configure these settings are located on the base of the dome drive. Figure shows the default settings for the DIP switches. Switch SW1-1 (SW1, switch 1) is set to the ON position. All other switches are set to the OFF position. Set the SW1 switches for the address of the dome drive.

Where are the DIP switches on a Pelco dome?

Pelco P-type controllers can operate at 2400, 4800, and 9600 baud. Set the SW2 switches (6, 7, and 8), located on the base of the dome drive, to the same baud as the Pelco P-type controller. SW2-9 should be set to the OFF position (default) if you are using coaxial cable.

What are the default switches for the dome drive?

Set the SW1 switches for the address of the dome drive. The following information is required to set the dome drive address: P-Type Control Default address is 2. Refer to Table A for address settings that use P-type control. Maximum number of receivers is 32. D-Type Control Default address is 1.

Figure shows the default settings for the DIP switches. Switch SW1-1 (SW1, switch 1) is set to the ON position. All other switches are set to the OFF position. Set the SW1 switches for the address of the dome drive. The following information is required to set the dome drive address: P-Type Control Default address is 2.

The DIP switches used to configure these settings are located on the base of the dome drive. Figure shows the default settings for the DIP switches. Switch SW1-1 (SW1, switch 1) is set to the ON position. All other switches are set to the OFF position. Set the SW1 switches for the address of the dome drive.

Why do I need a dip switch on my Motherboard?

DIP switches are useful wherever selecting a particular device function requires multiple switches to be toggled to achieve the right output mode. One of the most common applications for a DIP switch is on a computer motherboard, where various configuration settings can be accessed by toggling various switches to one position or the other.

Where are the contact pins on a dip switch?

The ‘dual in-line’ portion of the acronym refers to the arrangement of the contact pins underneath the DIP switch, which plug directly onto the PCB or breadboard – these are arranged in two parallel rows on the underside of the DIP switch block, hence dual in-line.
