A proper pilot flame should be blue with a yellow tip and should be strong enough to cover about 1/2 inch at the end of the thermocouple tip. If the flame is too strong and improperly adjusted, it will be blue but may be noisy and lift off the thermocouple, causing improper furnace operation.

How Big Should the flame be on a pilot light?

A proper pilot flame should be blue with a yellow tip and should be strong enough to cover about 1/2 inch at the end of the thermocouple tip. If the flame is too strong and improperly adjusted, it will be blue but may be noisy and lift off the thermocouple, causing improper furnace operation.

How do I adjust the pilot light on my boiler?

1. Locate the access plate on the front of your furnace, and unscrew the screws that are connecting the access plate to your furnace. …
2. Observe the flame. …
3. Turn that screw counter-clockwise, and the flame should grow.

How do you adjust the pilot on a gas stove?

Follow the pilot tube to the control handle until you see an air chamber, and there is where you’ll find the screw. Turn the screw clockwise in small increments to reduce the size of the pilot flame. To increase the flame size, turn it counterclockwise.

Can the pilot light on a gas fireplace be adjusted?

In either case, adjusting the pilot light is fairly easy. You’ll just need a screwdriver and a little patience, and you can fix the issue in a matter of minutes. First, locate the controls on the bottom of a direct-vent fireplace. … On others, there will be a screw that you can easily adjust with a screwdriver.

How do you adjust the pilot light on a gas log?

Turn the screw on the control panel to adjust the size of the flame. Use a screwdriver. A clockwise turn will make the flame smaller and the counterclockwise turn will increase it. If you have a lo-hi button on the fireplace – use it!

How high should the flame be on a gas fireplace?

Then, turn the gas on and light the pilot. Turn the burner on and set the flame height to high. Take a reading. This time, you want to see an ideal reading of 3.5 inches or the pressure rating indicated in the manual.

Where is the pilot light adjustment screw?

The adjustment screw is behind the cap screw. The screw should be turned to decrease the pilot flame.

Why is my pilot light so loud?

A – All control valves have a pilot adjustment screw. Turning it clockwise will reduce the flow of gas to the pilot. The optimum adjustment is just before the point it makes noise. … Another cause of excessive pilot noise is that the inlet pressure of the gas supply is too high.

What causes a weak pilot light?

The cause of a weak flame may also be an obstruction in the pilot tube. You can often remove such obstructions by turning off the gas, unscrewing the pilot tube from the valve control and blowing compressed air from a can through the tube. You can also poke the aperture of the pilot tube with a needle.

Article first time published on

Can a pilot light be too high?

A: There is a way to control the height of the pilot light flame. … The pilot flame should touch the thermocouple at a specific level. If the flame is blue and weak, and barely reaches the thermocouple, it needs to be stronger. If it extends well above the thermocouple, it’s too strong.

What should the pilot light look like on a gas fireplace?

A healthy pilot flame will be much like a blue “blow torch” flame. It will shoot sideways and be directly on your thermocouple and thermopile sensors. An unhealthy yellow pilot flame is more like a “candle”. It will shoot straight up in the air and will not engulf your sensors.

What color should pilot light be on gas fireplace?

The color of the pilot light should be blue because that means that only natural gas—without any other condensates—is reaching the pilot light through the gas main. The principal chemical compound found in natural gas is methane, and methane burns blue.

How do you adjust the airflow on a gas fireplace?

Insert a flat-blade screwdriver into the setscrew on the right side of the valve and twist counterclockwise to increase the gas-to-air ratio. Turn the setscrew clockwise to reduce air flow mixing with gas. Ask a friend to describe the flame color and intensity in your Heat-n-Glo fireplace to help with your adjustments.

How do you adjust the flame on a superior gas fireplace?

To Adjust the Flame or Turn Off the Fireplace To make the flame in the fireplace higher or lower, simply adjust it by turning the gas valve counterclockwise to increase it or clockwise to decrease it as desired. To shut down the fireplace completely, turn the gas valve clockwise all the way to the “off” position.

Why are the flames in my gas fireplace blue?

You get a blue gas flame with a hydrocarbon gas when you have enough oxygen for complete combustion. When you do have sufficient oxygen, the gas flame appears blue because complete combustion creates enough energy to excite and ionize the gas molecules in the flame.

What should a propane oven flame look like?

A normal, healthy flame on your burner will be mostly blue. Only the tiniest amount of yellow flame should be visible. Depending on if you use natural gas or liquid propane, that will appear in different places.

How do you adjust the flame on a GE gas stove?

The flame height may be adjustable. Pull the control knob off, if there is an adjustment screw in the center of the shaft, it is adjustable by a qualified gas technician.

Should you be able to hear a pilot light?

If it’s on, then turn it to off and leave it for a few minutes. If it’s off, turn it to pilot and hold it down (this causes gas to flow). When holding it down, you should be able to hear gas flow (it’ll be very faint noise).

Should I be able to hear my gas fireplace?

A gas fireplace should make little if any noise. … If your fireplace has a blower, a grinding noise or a high-pitched whistling sound usually indicates a problem with these components. Repair or replace the fan to fix this problem. A subtle roaring sound probably means the flame on your pilot light needs adjusting.

How can I make my gas fireplace quieter?

1. Tighten the burner assembly. As mentioned, a popping noise made by your fireplace can mean that the joints in the burner are leaking. …
2. Clean the fireplace blower. …
3. Clean the gas supply and pilot light from any obstruction.

How do you adjust the flame on a gas furnace?

All you will need to do is to twist the adjustment screw of the flame till the flame goes from one and half inches to two inches, which is about 4 to 5 centimeters high. Look for the adjustment screw on the pilot assembly close to the gas valve if the control valve has this adjustment feature.

What does the pilot screw adjust?

An air screw adjusts how much air is being delivered thru the pilot circuit: in is rich (less air) and out is lean (more air). A fuel screw adjust how much fuel (or air/fuel mixture) is being delivered from the pilot circuit. In is lean (less fuel) and out is rich (more fuel).

Should the pilot light always be on gas fireplace?

Should the pilot light always be on in a gas fireplace? Most gas fireplaces rely on a “continuous pilot light,” a type of pilot that remains lit so long as gas is flowing to the unit. … If you have a continuous pilot light system, you should always see a pilot flame unless you have manually turned the system off.

How do you adjust the pilot light on a Honeywell gas valve?

1. Remove the screw cap cover to the pilot light adjustment screw with a screwdriver. …
2. Use the screwdriver to turn the screw clockwise to lower the pilot light. …
3. Turn the screw counterclockwise to raise the screw which will raise the height of the pilot light.

How far should thermocouple be from pilot?

Remove the pilot tube from the gas valve and spray compressed air to clear it. When working properly in most gas appliances, the pilot flame should hit the upper 1/2 to 3/8 of the thermocouple. If the pilot has a weak, orange-yellow flame or barely reaches the thermocouple, it’s too low.

How do I stop my pilot light from blowing out?

You should hold down on the pilot light for at least five seconds once it is lit before letting go. This will ensure your pilot light won’t blow out right after you light it.

How do you clean a clogged pilot light?

Use your pliers or wrench to remove the pilot light and thermocouple from the bracket. Using the wire brush, brush away the carbon buildup and soot from both components. For hard to reach areas and stubborn buildup, use the metal file. Wipe away dust with a soft cloth or burst of compressed air.

How big should pilot flame be on boiler?

The flame should strong enough to cover about 1/2 inch at the end of the thermocouple tip. If the flame is too strong and not adjusted correctly, it will be blue and may make a hissing sound as the flame crosses the thermocouple. The pilot should be adjusted to reduce the intensity of the flame.
