The intraosseous needle may remain in situ for 72 to 96 hours, but it is best removed within 6 to 12 hours, as soon as an alternative site of intravascular access has been established. The intraosseous route provides fast and reliable vascular access in emergency medical situations.

How long can an IO stay in place?

The IO site can be used for 24 hours and should be removed as soon as intravenous access has been gained. Prolonged use of an IO site, lasting longer than 24 hours, is associated with osteomyelitis (an infection in the bone).

How fast can you run fluids through an intraosseous cannula?

The maximum rate of administration through the IO needle was reportedly equivalent to a 21 G peripheral cannula [23]. The flow rates of an intravenous cannula are typically in the range of 200 (16 G peripheral cannula) to 20 ml/min (24 G peripheral cannula) [30].

When should an IO be removed?

All IO lines should be removed within 24 hours of the insertion time or earlier if there is any sign of extravasation (i.e. progressive pain or swelling at the insertion site).

How painful is an IO?

The procedure is both safe and effective in children and adults. IO access can be extremely painful. However, the patient’s pain level can be reduced to a bearable level by injecting 2% preservative-free lidocaine through a special port before starting the infusion.

How can you confirm the IO needle is in the correct position?

Use a twisting motion with gentle but firm pressure. until there is a sudden release of resistance as the needle enters the marrow space. If the needle is placed correctly, it should stand easily without support.

Can you push blood through an IO?

Any intravenous fluid, blood products or routine resuscitation drugs can be administered through the IO route. Complications for short-term use are relatively rare compared to the advantages for a child who needs rapid administration of blood or fluid.

Can glucose be given io?

Intraosseous infusion of hypertonic glucose and dopamine is an effective route by which to administer these medications and is potentially useful in emergency situations in which intravascular access is delayed.

How is an IO removed?

To Remove IO: Remove extension set from needle hub and attach a 5 or 10mL sterile syringe with standard luer lock to act as a handle and cap the open IO port. Grasp syringe and continuously rotated clockwise while gently pulling until the needle is removed.

What site is the first choice for intraosseous infusion?

The proximal tibia, humeral head, and sternum are the preferred sites in adults. The distal femur, proximal tibia, and distal tibia are preferred sites for infants and neonates.

Article first time published on

Is IO quicker than IV?

An IO is a quick way to get vascular access in a code, faster than an IV and with greater first-attempt success.

Why do paramedics drill into leg?

A bone drill is used when a traditional IV cannot be secured on a patient. It could be because the patient is dehydrated, diabetic or under extreme trauma, Shubert said. The bone drill can be used to quickly insert an intraosseous needle directly into the bone to dispense fluids, medications or sugar.

Is Io a central line?

IO techniques have fewer serious complications than central lines, and they can be performed much faster than central or peripheral lines when vascular collapse is present. IO insertion is recognized to be both safe and effective in all children and adults.

Can you saline lock an IO?

9. Connect the appropriate IV equipment (normal saline locks not indicated in IO placement). 10. Administer the appropriate fluids and/or drugs.

Where does IO needle go?

The needle is placed on the broad, flat anteromedial surface 1 to 3 cm distal to the tibial tubercle. The distal femur is an alternate site. The needle is inserted 2 to 3 cm above the lateral femoral condyle, in the midline and angled 10 to 15 degrees cephalad.

Who can put in an IO?

RN’s, physicians or EMT-P’s may insert an IO device after they have completed instruction with clinical supervision. An order must be received to by a physician for a RN or EMT-P to insert an IO. 3.

Can you give propofol io?

Two IO doses of propofol (1 mg/kg) were administered during the direct laryngoscopy to achieve a deeper plane of anesthesia. After completion of the airway examination, which required 15 min, the infant was transported to the pediatric ICU with the IO needle in place.

When can IO access not be used?

In a general manner, IO access should not be used in severe genetic or acquired bone diseases, imperfect osteogenesis, osteoporosis and osteomyelitis [17].

What drugs can you give Io?

While all resuscitation drugs can be given by the IO route, administration of ceftriaxone, chloramphenicol, phenytoin, tobramycin, and vancomycin may result in lower peak serum concentrations. The most common adverse effect seen with IO use, extravasation, has been reported in 12% of patients.

When should IO access be attempted before vascular?

Indications. IO access is the recommended technique for circulatory access in cardiac arrest. In decompensated shock IO access should be established if vascular access is not rapidly achieved (if other attempts at venous access fail, or if they will take longer than ninety seconds to carry out.)

How do you know an IO is in place?

There are already multiple methods for confirming IO placement, including return of bone marrow, visualization of blood in the stylet, firm placement of the needle in the bone, and the ability to smoothly deliver a fluid flush.

When should Io be attempted before IV?

D. IO placement may be considered prior to peripheral IV attempts in cases of cardiopulmonary or traumatic arrest, in which it may be obvious that attempts at placing an IV would likely be unsuccessful and or too time consuming, resulting in a delay of life-saving fluids or drugs. 1.

How do you remove the EZ IO needle?

The EZ-IO® must be removed within 24 hours from the time of insertion. Remove any extension set and dressing and attach a luer-lock syringe to the hub. While maintaining axial alignment, twist the syringe and catheter clockwise while pulling straight out (Figure 4). Do not rock or bend during removal.

Is IO better than IV?

Intraosseous (IO) parenteral access is relatively fast and easy to obtain, whereas intravenous (IV) access can be difficult. IO access is currently recommended as an option for patients with out-of-hospital cardiac arrest (OHCA) when IV access cannot be immediately obtained.

Can you push d50 in an IO?

Answer: Dextrose can be given via IO. Literature reports that the problem with dextrose and bone marrow is seen with long term administration / infusions of dextrose IO rather than in an emergency situation – temporary and once or twice for a single patient – when bolused and flushed.

How do you insert an intraosseous cannula?

Insert the intraosseous needle Firmly hold the drill or the manual needle in your dominant hand. Position the needle tip at the point of insertion, perpendicular to the long axis of the bone. Point the needle slightly (10 to 15 degrees) away from the joint space and growth plate.

How do you start an intraosseous line?

Place the needle through the skin, perpendicular and down to the bone. Activate the IO drill or gun until the IO needle anchors in place, OR manually TWIST the needle clockwise (don’t push) with gentle firm pressure until the bone gives (loss of resistance technique) and the needle locks into place.

How do you secure an IO needle?

Place the padded mask over the IO needle. The IV tubing can be threaded through the hole at the top of the mask. Secure the mask by wrapping circumferential tape around the extremity and mask as a unit. This mask trick works whether the IO needle is in the tibia, femur, or humerus.

When was IO access invented?

The concept of intraosseous access was first introduced by Harvard physician, Dr. Cecil K Drinker, in 1922. He recognized that the bone marrow cavity provided a non-collapsible vein that could be used to administer drugs and fluid therapy when intravenous access wasn’t possible.

Can Adrenaline be given io?

Background: Adrenaline is an important component in the resuscitation of individuals experiencing out-of-hospital cardiac arrest (OHCA). The 2018 Advanced Cardiac Life Support (ACLS) algorithm gives the option of either intravenous (IV) or intraosseous (IO) routes for adrenaline administration during cardiac arrest.
