How does a Posi Temp shower valve work?

By controlling the turning range of the handle on a Moen PosiTemp valve, these temperature limit stops restrict the water temperature range, meaning it cannot get too hot or too cold. This will increase or decrease how hot or cold your water temperature will get.

What kind of handle does Moen shower handle use?

Moen produces a variety of single handle shower trims. The interior components and assembly are not the same for each model. This article will explain one of the more common handle assemblies referred to as a Lever 2. This is for a Positemp Valve System, and it utilizes a 1222 cartridge.

When was Moen Posi temp shower valve introduced?

The original Moen cartridge, the 1200 provided one-handle operation. It was used in all one-handle faucets, except the Posi-Temp shower valve, prior to the introduction of the 1225 in 1981.

Where is the handle on a positemp valve?

Position the handle (#2) back onto the handle adapter (#4). Turn the handle (#2) to the off position to reinstall the 7/64″ hex screw (#1). Note: If after testing you notice the hot and cold are reversed, see article How to Reverse Hot and Cold for a 1222 Cartridge.

How do you install a positemp shower handle?

Install the key stop (#6) into the stop tube (#7) with the raised ridge at the the top and then install the temperature limit stop (#5) into the key stop (#6). Slide the handle adapter (#4) onto the stem of the cartridge.

What is moentrol by Moen?

The Moentrol valve has a pressure-balancing mechanism and uses the 1225 cartridge. It can adapt to Moen’s two- or three-function transfer valves as needed for the addition of handshowers or for vertical spas. The Moentrol valve is also available with an integrated two- or three-function transfer valve option.

What is posi temp faucet?

A posi temp faucet has a handle that rotates a quarter turn in one direction for hot water and a quarter turn in the other direction (from the center mark) for cold water. The Moen posi temp faucet is the only one in Moen’s line that has this particular type of valve.

What is posi temp valve?

The Posi-temp is a pressure-balanced valve. This means that the valve maintains the selected flow of hot and cold water even with fluctuations in the pressure of either temperature water supply. So, if someone flushes the toilet while your in the shower – the shower temperature is unaffected.
