How do you take apart a Kohler Single handle shower faucet?

Firmly grasp the handle. Turn the bonnet counterclockwise and remove the handle and bonnet from the valve stem. Using a Phillips screwdriver, unthread the two screws and remove the handle sleeve, shroud, and faceplate. If applicable, use a flat-blade screwdriver to remove the pin from the adaptor.

How do you replace a handle on a Kohler faucet?

Install the new valve by screwing it back into the faucet, turning clockwise. Tighten the valve with the wrench to 1/8 to 1/4 turn past hand tight. Before reassembling the handle, turn the water back on to check for leaks. Once you have made sure there are no leaks, reassemble the remaining parts. Fig. 1 Fig. 2 Fig. 3 Fig. 4

How do you remove the seal from a Kohler shower?

Using a Phillips screwdriver, unthread the two screws and remove the seal plate. If applicable, use a flat-blade screwdriver to remove the pin from the adaptor. Unthread and remove the adaptor from the valve. Using a 3/32” hex wrench, loosen the two setscrews. You may need to rotate the sleeve to access both setscrews.

How to remove a single control shower valve?

1 Using a 3/32” hex wrench, loosen the setscrew and slide the handle and adaptor off the valve. 2 Slide the sleeve off the valve. 3 Using a Phillips screwdriver, unthread the two screws and remove the faceplate. 4 If applicable, use a flat-blade screwdriver to remove the pin from the adaptor. Unthread and remove the adaptor from the valve.

How do you install a new water faucet?

Install the new valve by screwing it back into the faucet, turning clockwise. Tighten the valve with the wrench to 1/8 to 1/4 turn past hand tight. Before reassembling the handle, turn the water back on to check for leaks.

Can you repair a Kohler two handle faucet?

Although Kohler faucets are made with the highest quality, like anything else with moving parts, they may need service from time to time. Kohler faucets are designed for the homeowner to repair. Installing new valves in a two handle faucet is something almost anyone can do! Turn off the water to your faucet and remove the handle (Fig. 1).

How do you remove a Kohler shower handle?

Using a Phillips screwdriver, unthread the two screws and remove the handle sleeve, shroud, and faceplate. If applicable, use a flat-blade screwdriver to remove the pin from the adaptor. Unthread and remove the adaptor from the valve.

Can you replace the handles on an old tub?

Giving your bathroom a much-needed facelift doesn’t require a massive budget or a lot of time. Replacing the spout and faucet handles on an old tub is one way to improve the bathroom’s overall look quickly and easily. While faucet handles are held in place by a screw, tub spouts can be attached in one of three ways.

How to remove single-control bath or shower trim to?

This document is intended to help identify and remove the trim from your KOHLER single-control bath or shower valve. Identify your valve trim by referring to the thumbnails, then follow the instructions listed below the image to remove the trim.
