How do you light the pilot on a Whirlpool water heater?

When lighting the pilot, make sure the knob on the gas control valve is fully pushed in. Keep the knob pushed in while repeatedly clicking the spark igniter button. Hold the knob in and click the igniter button repeatedly for 90 seconds. Newly installed water heaters have air in the gas line.

How do I reset my Whirlpool gas hot water heater?

Use a flashlight or a headlamp to find the burner inside. Turn the gas knob to “Pilot,” press and hold it down. While still holding the gas down, light that pilot. When the flame ignites, continue to hold the gas knob or button down for a full minute.

What would cause the pilot light to go out on a gas water heater?

Some of the most common reasons that water heater pilot lights go out include: A faulty thermocouple. Over time, thermocouples can begin to malfunction and shut off the gas supply to the pilot light even if it’s burning properly. A bent or dirty thermocouple.

Where is the pilot light on my water heater?

Make sure the valve is running parallel with the pipe. If it is perpendicular, that means it if off. Locate and remove the bottom cover of the water tank. Depending on your water heater, you can actually see if there is a flame underneath the tank. Turn the pilot light knob onto “pilot”.

How do you light the pilot light on a gas fireplace?

Remove the front cover of the appliance to access the pilot light area. Some appliances, such as a gas fireplace, may have an open pilot light area. Use a screwdriver to remove the screws to open the panel if needed. Turn the pilot control knob to the “pilot” position. Light a match and hold it directly beneath the tube in the pilot opening.

How does the pilot light on a gas range work?

On some gas-powered appliances — such as gas ranges, water heaters, boilers and gas fireplaces — the pilot light works to ignite the main flame when the gas is switched on to the burner by the regulating valve. If the pilot light is not lit, the gas burner will not ignite,…

How do you relight a hot water heater?

Press down on the knob and hold down the ignite button for a minute to turn the flame back on. Once a flame is ignited, you can rotate the knob to whichever temperature setting you would like. If you cannot hear a subtle gas sound underneath, you may need to call a technician to troubleshoot your water heater.

Why does my whirlpool water heater need pilot light?

A newly installed gas water heater will have some air in the gas line. For this reason, it may take several attempts to light the pilot. Many times, the pilot will be lit, but it can be hard to see. Newer water heaters are more energy efficient and have much smaller pilot lights than older models.

How can you tell when your water heater has a pilot hole?

You can usually tell when this is about to happen because the pilot flame becomes smaller, and it burns with a orangish-yellow hue. You can clear the pilot orifice with a piece of wire or a wire brush, and it isn’t difficult to access.

Where is the pilot tube on a water heater?

Follow the gas line from the heater to the gas supply shutoff valve and turn off the valve. The valve is off when it’s perpendicular to the pipe. Locate the pilot tube. It is one of two small tubes connected to the automatic gas valve; the other is the thermocouple tube.

What should the water pressure be in a whirlpool water heater?

Note – If large quantities of hot water are coming from the discharge pipe, turn electrical power off and consult a qualified technician. Do not cap or plug the discharge pipe. Check your home’s water pressure with a gauge. The recommended water pressure is 50 to 60 PSIG.
