A simple method is to create a drainage tube with a length of permeable membrane and gravel. Before back-filling the soil behind your retaining wall, lay a length of permeable membrane at the base of the wall then cover half the width next to the wall with a 20cm wide and 20cm deep layer of large gravel or ballast.

What do I need to build a sleeper wall?

A simple method is to create a drainage tube with a length of permeable membrane and gravel. Before back-filling the soil behind your retaining wall, lay a length of permeable membrane at the base of the wall then cover half the width next to the wall with a 20cm wide and 20cm deep layer of large gravel or ballast.

How thick should a sleeper wall be?

When constructing a wall with sleeprs it is important that your sleeper of choice is at least 75mm thick otherwise over time it will warp.

Can you lay sleepers on soil?

For one, you can simply place your sleepers directly onto soil, allowing the heavy sleepers time to bed in. … Simply dig a shallow trench and place your sleepers down onto your newly created gravel or sand-based foundation.

How do you anchor sleepers to the ground?

Cut your sleepers to your required length, which could be random for a rustic look. Then mix up some lean mortar, such as 6:1, to be used as a concrete base and haunching. Place at least a 50mm bed of concrete in the bottom of the trench and start inserting the sleepers, haunching them up as you go.

How do you prevent sleepers from rotting?

To preserve the sleepers further, we would recommend treating them with an exterior wood oil or decking oil, ideally twice a year in Spring and Autumn. This will help to repel water and prevent water ingress, the main cause of wood rot.

How do you connect sleepers?

When building sleepers in layers, it’s a really good idea to overlap the right-angled corners for added stability and strength. Simply place your length or frame on top of the first layer so the joins are overlapped like a brick wall, then work in the same way to secure.

How high can I build a sleeper retaining wall?

This system works for sleeper walls up to 1200mm in height; anything higher than 1200mm needs to be designed by an engineer to take account of local ground conditions and loadings.

Can you lay sleepers on sharp sand?

If you wish to add finishes or other treatments to your sleepers, this is the best time to do so. Laying sharp sand into your channels or in the dug area of your pathway will ensure each board has a nice even foundation. Pour in a layer of around 25mm and pack it down using one of your sleepers or a tamper.

How deep should Sleeper posts be?

Retaining wall posts should be at least as deep as the amount of soil they will be holding. A good rule of thumb is to halve the height of the wall and then add 4 inches. This is how deep you should place your posts.

Article first time published on

What is the cheapest way to build a retaining wall?

The cheapest type of retaining wall is poured concrete. Prices start at $4.30 per square foot for poured concrete, $5.65 for interlocking concrete block, $6.15 for pressure-treated pine, and about $11 for stone. Installation or supplies, such as drainage stone or filter fabric, are not included.

Does a 2 foot retaining wall need drainage?

These walls need a drainage system regardless of the wall height. If there are poor draining soils such as clay behind the wall, there needs to be drainage incorporated the wall system. Clay when wet is very weak, so it is essential to provide a way for water to escape from behind the wall.

What sleepers are best for retaining wall?

Wooden sleepers are an excellent alternative to bricks or concrete for building retaining walls in your garden. Not only do they look beautiful, but they are often a much more affordable option. Garden sleepers can be used both horizontally and vertically when building a retaining wall.

What should I Bed railway sleepers on?

The railway sleepers should ideally be laid on a surface that is level and firm. Many people simply lay them down directly on the earth, grass, deck or concrete.

How long will sleepers last in the ground?

As a rule, hardwood oak sleepers tend to last the longest naturally with an expected lifespan of around 100 years. An untreated softwood will last for between three and five years if it sits on the ground, whilst treated softwoods can last between 20 and 30 years if they are maintained correctly.

What screws to use for sleepers?

Timberlok screws are an alternative to traditional coach screws and can be used in a number of timber to timber applications. One of the most popular uses for Timberlok screws is fixing timber sleepers together.

Can you stain sleepers?

As with the contemporary sleepers, you won’t need to add a finish to solid redwood sleepers, but they could benefit from a range of finishes, such as a wood stain or sealant, which can help the longevity of your railway sleepers.

Will sleepers rot in the ground?

Like all wood, sleepers will eventually rot and fade when exposed to the weather. To prevent them falling to bits before their time, you need to use a good wood preserver.

Do sleepers need to be treated?

Wood Preserver Reclaimed railway sleepers can last for decades without being treated. However, to help nourish and protect the timber from decay it is a good idea to apply a wood preservative.

Can you use Postcrete for sleepers?

Fixing Sleepers There are three main methods for securely attaching sleepers to the ground. … Screw-fix a metal log roll pin or wooden stake – one to each end of the sleeper. Dig a 75mm deep trench and use postcrete to provide a base 25 – 30mm deep.

How far apart do retaining walls need to be?

Retaining wall posts should be at least three feet apart. The distance can be slightly longer or shorter if it works better with your measurements. However, you shouldn’t go more than seven feet apart to make sure your wall is sturdy enough.

How far apart are retaining wall posts?

Each post should be 3 feet (0.91 m) away from each other—start by marking the first post location with chalk at one end of the wall.

Does a 4 foot retaining wall need drainage?

The design and performance of most retaining walls are based on keeping the area behind the wall relatively dry. … Any reinforced wall or walls over 4 ft. (1.2 m) in height or with slopes or other surcharges above the wall will need a toe drain.

Can you use sand as a base for a retaining wall?

To keep the blocks on your retaining wall level and structurally sound, you need a base layer of several inches of well compacted, sharp gravel. … Be sure to use coarse builder’s sand, and tamp it down firmly to keep the sand from shifting and settling after the wall is built.
