Start at that sprinkler and try to find the valve nearby. The cheapest and easiest way to find buried irrigation valves is often to probe the soil with a thin rod, such as a long screwdriver. Often you can estimate the rough location of the irrigation valve, then find a buried valve box by probing the ground.

How do I find an underground irrigation line?

You can tell (roughly) where the pipes will be for that zone by finding the shortest path from the valve box that connects all the sprinklers in a zone. As long as you dig carefully, you shouldn’t have too much trouble. The pipes are usually pretty tough and are usually buried about a foot or so under the ground.

How deep are irrigation systems buried?

Dig for Your Sprinkler System The trenches will be relatively shallow, usually 6 to 12 inches deep, depending on your area’s freeze cycles and frost severity. The trench must also be deep enough to allow the sprinklers to retract underground to prevent breakage from lawn machines.

How can I find my sprinkler lines without digging?

If you prefer to locate the lines and heads of your system without digging, rent a valve locator or even a metal detector and mark areas once found – better yet, call call 811, a federally mandated service, and ask someone to come out and locate the system for you.

How do I find my irrigation system?

To calculate the amount of water you use, multiply the width times the length of your yard in feet to get the number of square feet of area. Then multiply that figure by 0.623 to come up with the number of gallons used (or use our calculator below).

How far do you bury sprinkler lines?

In most areas, burying the pipes 8 to 12 inches below the surface is adequate. This measurement is from the top of the pipe to the surface of the soil, which means your trenches must be slightly deeper to accommodate the pipes.

How do I find buried sprinkler heads?

Use a shovel to gently scrape the dirt from the area to find each buried head. Use a metal detector to find buried sprinkler heads. Many valves have metal parts you can locate by running the metal detector over the surface of the ground. Valves are located directly under sprinkler heads.

LENGTH OF RUN LIMITS: ½ inch tubing can run up to 200 linear ft. ¼ inch tubing should not exceed 19 ft in length. MAXIMUM FLOW CAPACITY: ½ tubing can handle a maximum of 240 GPH or 4 GPM.

How much water does irrigation use?

How do you dig out a sprinkler system?

How far can you run irrigation pipe?

Watering with a typical sprinkler using a standard 5/8" garden hose for one hour uses about 1,020 gallons of water; if you water three times per week, that's about 12,240 gallons per month.

How many zones does my yard need?

Article first time published on

Draw Your Sprinkler Zone Plan With simple math, you can determine how many heads in each zone and then take the total number of sprinklers you need, and divide that by your head/zone number and that will tell you how many zones you ne

How much water pressure is needed for a sprinkler system?

The optimum operating pressure for most residential sprinkler heads is between 30 and 50 pounds per square inch (PSI). With correct water pressure, each head will perform the way they were designed, and the result will be even spray-patterns

How do you find sprinkler heads without turning them on?

Pull a metal garden rake gently over the area of the grass where you suspect sprinkler heads are located if you cannot turn water on to the system. If the sprinkler heads are buried, you may need to apply greater pressure to the rake so it di

Can a metal detector find sprinkler valves?

If your pipes are metal, the metal detector won't tell you the location of the valve box, but it will tell you where the pipes are, so you can dig along the pipe to find the valve.

Should irrigation valves be buried?

Valves can be grouped together in manifolds, or installed individually - and valves should always be buried inside a plastic irrigation valve box. Never bury a valve directly in the dirt.

How do pop up sprinklers work?

Pop-up spray sprinklers spray water over the whole area to be watered the entire time it is watering. They are hidden underground and set to pop up and retract with timers. Pop-up rotors spray a solid rotating stream of water to cover large a

Can drip irrigation tubing be buried?

Drip irrigation can be buried underground or laid over the top and covered with mulch. ... Weaving drip irrigation through your garden or burying it just underneath the soil will ensure that crops get the proper amount of hydration.

How far can you run a 1 water line?

Re: Most DEPENDABLE water line? 400 feet is too long for a 1" pipe in most cases. I would increase it to 1 1/2" or even 2" to avoid the pressure loss caused by that distance. At that size, PVC is about the mose economical and if installed pro

How long should you run a sprinkler?

Sprinklers should be set to run for about 30 to 35 minutes at a time twice a week. Your goal is at least 1″ of water a week for your lawn. When it's hot and dry, double the water times while still trying to water just 2 or 3 days a week.

How many minutes should I water my lawn?

It is ideal to water lawns about one inch of water per week. To determine how long you need to water to get one inch, place a plastic container in your yard and set a timer. On average, it will take 30 minutes to get a half inch of water. So, 20

How many heads are in a zone?

At different pressures, the sprinkler head and nozzle will consume different amounts of water. For example, at 35 pounds per square inch (PSI) the 5000 Series Rotor using the 3.0 nozzle will use 3.11 gallons per minute (GPM). If your home's water ca

How long after you lay sod can you walk on it?

If you walk on your sod before its roots have established, you're lessening your chances of success. How long must you wait to use your new sod lawn? The general recommendation is to wait two weeks – but the number of days you wait is really

How do irrigation zones work?

The zones will be set up with different sprinkler heads and watering systems to make sure water covers the area. Your bushes and shrubs will need less water than grassy areas. ... Once the irrigation system is installed, it can be set so each

How many sprinkler lines do I need?

If you wish to calculate sprinkler layout manually, first determine the area of your yard by measuring its length and its width in feet. Then, multiply these numbers together. You may want to draw your yard to scale on a piece of graph paper. Eac

How do I increase water pressure in my irrigation system?

Remove a few sprinkler heads from each of the zones in your system and cap the plumbing that led to them. Decreasing the number of sprinkler heads will increase the water pressure in those that remain. Install a boost pump on the main irrigat

How many sprinklers can I run on one line?

For example, you generally have a flow rate of 10 gpm from a ¾-inch spigot where you connect your hose. With your 10 gpm flow rate at your spigot, you could run two sprinklers at 5 gpm each. The best set-up is to run two hoses from the spigot

How deep are pop up sprinklers?

They advise that pipes should be trenched to a minimum of 400mm (15.8 inches) below the surface. This is to help avoid accidental punctures of the pipe and therefore lower maintenance costs in the future.

Where is the main sprinkler system valve usually installed?

In newer lawn irrigation systems, the valves should be installed in valve boxes. These can often be seen easily. There is a single valve box located near where the irrigation pipes enter the ground in small yards.
