HVAC equipment and ductwork should not be located in the garage where it can act as a conduit for air movement between the garage and the house. … They can be installed in a utility closet or utility room in the home, in an unvented attic, or in an insulated and air-sealed basement or crawlspace.

Where should I place my air handler?

To avoid the need for long ducting that can reduce efficiency, the air handler is best installed as close to the center of the home as possible. Two common installation choices are a utility closet inside the house or a well-sealed equipment room in the garage.

Can I put my air handler in a closet?

If a full closet return (i.e., air handler on stand in closet) is unavoidable, seal all joints, seams, and edges of the closet air barrier (e.g., drywall, floor finish, sub-floor). Install an air barrier, if necessary, to enclose wall cavities and separate the closet from the attic.

Can you put a air handler outside?

It is always the case that an air handler is located inside, but it is not always the case that the stuff inside an air handler have to be inside. For example, a packaged unit combines the compressor, condenser and evaporator coils, and the fan in one big cabinet that is always installed outside.

Do air handlers need venting?

An air handler is also all electric and does not require venting any exhaust outside. The only way an air handler can heat air is by using an outdoor heat pump or by adding an optional electric heat element.

Can I put a mini split in my garage?

It turns out that a mini split air conditioner is an excellent choice for heating and cooling a garage. Mini splits are very efficient and they operate incredibly quiet. Mini splits are a space saver because they don’t require ducts and they are mounted up high on the wall.

How long should an air handler last?

Air conditioning units generally last around 15 years or so. If you want your air conditioning unit to live as long as possible, you want to get it maintained twice a year.

Can you put mechanical room in garage?

Sadly, the answer is yes. The building codes say you can put your HVAC system and ductwork in a garage as long as you meet certain requirements. Here are two references: Mechanical Code 304.6: Appliances located in private garages and carports shall be installed with a minimum clearance of 6 feet above the floor.

Can you install air handler in attic?

If you are going to install an AC handler in the attic, it is important that you have your attic properly insulated. Without proper insulation, cool air could be lost, and excess moisture could develop.

Can air handler be bigger than condenser?

Yes, it’s bad if your evaporator coils are sized bigger or smaller than your condenser coils. In fact, if the size of your evaporator and condenser coils don’t match, it can result in: Higher monthly energy costs. Reduced unit lifespan.

Article first time published on

How much is an air handler unit?

New Air Handler$700 – $1,500Installation$1,200 – $1,800Remove/Dispose of Old Unit$300 – $500Total$2,200 – $3,800

Do air handlers make noise?

Unusually noisy motors inside air handlers and furnaces make squealing, screeching, rattling, and/or banging noises when the equipment malfunctions. In most cases, these are inexpensive repairs—adding lubricant, tightening parts, and replacing belts.

Is air handler in attic bad?

The biggest complaint about attic HVAC units is that they don’t really make sense. Attics are, for the most part, unconditioned, meaning a leak here could significantly reduce your home’s overall efficiency. … But even if the ducts are installed to a tee, there’s still the possibility that leaks will develop.

What size air handler do I need?

Size your air handler. Size your air handler unit based on the size of your air condenser unit. If your air condenser unit needs to be four tons so must your air handler. You can put a larger air handler by one ton more, but for optimal performance they should match.

How do air handlers heat?

When the refrigerant enters the coil in the air handler, it releases that heat. The coil gets very hot. The blower pulls cool air into the air handler and over the coil. The air is heated and blown through the ducts into the rooms of your home.

What is a split system air handler?

What is an HVAC Split System? An HVAC split system is for homes that have space for large indoor cabinets. The split system model holds the condenser and compressor in an outdoor cabinet. Another indoor cabinet will hold the evaporator coil, and an air handler sends the cool air through the duct system.

Why is water leaking from my air handler?

It can be several things such as a clogged condensate drain line, the drain pan is damaged or rusted, the condensate pump is broken, the air filter is not clean, or the refrigerant is low.

Do you have to replace air handler with a heat pump?

You should replace your air handler when you replace your air conditioner or heat pump because matched systems perform better. … Additionally, if your heat pump or air conditioner is 10 years old or older, it’s time to replace it anyway.

Does the air handler and condenser have to match?

The short answer is that a handler and condenser can be different brands and the unit will function properly. … Ideally, it is better to match the same brand of condenser and handler if possible, and have them both replaced together.

How much does it cost for a new HVAC system?

The cost to replace an HVAC system averages $7,000, with a typical range of $5,000 to $10,000. This translates into $25 to $60 per square foot of coverage, depending on the brand and size. For a new installation, you can expect to pay.

How much does it cost to put AC in a garage?

Expect to pay $350-$1,000 for the AC based on the size and quality of the unit and whether it produces heat too. Hiring a handyman to cut the hole in the wall and installing the unit will cost $250-$750 for most projects.

Can I air condition my garage?

A garage air conditioner is a sure-shot way to make your garage as cool as your bedroom. But opt for this option only if you are spending a considerable amount of time within the garage. Suitable air conditioners for this option are either a window air conditioner or ductless wall-mounted mini-splits.

Can you install AC in a garage?

Depending on where you live, the temperature in your garage may be hotter than recommended, or desired. Because of this, we often get asked if it’s possible to put an air conditioner in the garage, or if it’s even safe to do so. The short answer is — Yes you can. And yes, it’s safe if done correctly.

Why is my air handler sweating in the attic?

If an air handler is in a garage, attic, crawlspace, or closet, it might experience less air flow and humid air. … Hot, humid air mixes with the cold internal air of the air handler by the cold metal of the unit causing condensation.

How do I stop my air handler from vibrating?

Lack of Dampers Fortunately, you can effectively eliminate air handler vibrations through the installation of a vibration dampener. An HVAC technician installs this component, also sometimes referred to as a vibration isolator, between the air handler’s supply plenum and the supply duct.

How do I stop condensation on my air handler?

1. Check the Duct Insulation. …
2. Seal the Crawlspace. …
3. Check Your Airflow. …
4. Remove Drain Blockages. …
5. Check the Temperature Setting. …
6. Install a Larger Unit.

Can you put a house furnace in the garage?

To run most efficiently, your furnace will need a space with ample fresh air, a source of natural gas, and proper ventilation. These necessary components can be found in large spaces like basements, utility rooms, and garages as well as confined spaces like an attic or closet.

Do mechanical rooms require ventilation?

All mechanical rooms must be mechanically ventilated to maintain room space conditions as indicated in ASHRAE 62, ASHRAE 15, and Table 5-1 of this chapter. … Mechanical rooms shall have floor drains in proximity to the equipment they serve to reduce water streaks or drain lines extending into aisles.

Can a furnace be in a garage?

Garages: Many furnaces are placed in garages. … However, in homes with a larger laundry room, the furnace may be placed there. Attics: In homes with limited space, the furnace can be installed in the attic.

Can you use a 5 ton condenser with a 4 ton air handler?

A 5 ton outdoor unit will not work with a 4 ton indoor coil and air handler or furnace. The freon won’t boil off correctly.

What is the difference between an air conditioner and an air handler?

Air handlers are designed to move air around. That’s all that they do. They don’t heat up or cool down, they move air. Air conditioners, on the other hand, exist only to cool air by removing heat from the outdoor air.
