Can blue water pipe be used above ground?

CAN I USE BLUE MDPE POLYETHYLENE PIPE ABOVE GROUND? Blue MDPE plastic pipe is designed for below ground use, however it may be used above ground in situations where it is not exposed to light and is protected against: undue warming, freezing, and.

How deep should MDPE pipe be buried?

According to ‘The Department of the Environment’, they recommend that pipes should be buried at least 600mm (two feet) underground. At this depth, the soil acts as a natural insulator and prevents them freezing.

What is the best type of pipe for underground water line?

Although there are many options for underground water pipes, HDPE pipes and PEX pipes are generally the best choices for an underground water line. These durable pipes are resistant to corrosion and rusting, ideal for running an underground water line.

Can I join MDPE pipe underground?

Suitable for underground cold water services, our range of MDPE fittings have an improved collet and stainless steel teeth the provide extra grip onto MDPE pipe. Manufactured to strict British Standards our MDPE fittings are also WRAS approved.

What is the blue water pipe called?

MDPE pipe is sometimes referred to as, alkathene pipe, pe pipe, water pipe, poly pipe, blue water pipe and pe80 pipe.

How deep in the ground are water pipes?

Usually 12″. No need to go any deeper since we don’t get that cold. Shallow water lines tend to get hot and since most yard piping (meter to home) is PVC you may encounter a poor taste.

How deep do you need to bury water pipes?

12″
Water filled pipe should be buried at least 12″ below the maximum expected frost line. It is recommended that thermoplastic piping be run within a metal or concrete casing when it is installed beneath surfaces that are subject to heavyweight or constant traffic such as roadways and railroad tracks.

Can Mdpe fittings be buried?

It is crucial that fittings buried underground are installed correctly first time, as the cost to rectify any issues can be huge and destructive. MDPE fittings are reliable and designed to suit this type of environment.

Can a blue MDPE pipe be used above ground?

Blue MDPE pipe is approved for use below ground for potable mains water conveyance. Black MDPE pipe is virtually the same, but has additional UV protection for use above ground in general water applications. Pipestock have vast stocks of blue and black MDPE pipe, available for fast, reliable delivery.

How big is a blue water supply pipe?

BS 6572: Blue polyethylene pipes up to nominal size 63mm for below ground use for potable water. This pipe is specially developed for services laid in the ground. It is pigmented blue and there is one class designed for a working pressure of 12 bar at 20ºC in sizes up to nominal size 63mm. Selection of pipe size

What’s the difference between Blue MDPE and black MDPE?

Black MDPE vs Blue MDPE – what’s the difference? Under BS EN 12201 plain black MDPE is used for above ground drinking water (potable) systems, whereas blue MDPE is used for drinking water systems below ground. Pushfit compression fittings are typically used in this application for sizes 20-63mm, and electrofusion fittings for larger diameters.

What kind of MDPE to use for water pipe?

Water Pipe: Blue MDPE for drinking & Black MDPE for general water supply. Water supply pipe can be installed using various procedures and techniques, with modern pipelaying techniques offering low-dig or no-dig laying possibilities, and conventional open cut trenching still being the most common install method.

How big does MDPE pipe have to be to run above ground?

Be prepared to dig though!!! The supply must be buried a minimum of of 750mm, Blue MDPE pipe is not designed for above ground use, you will have to check with your water authority, how they wish the pipe run to be installed, if you wish to come out of the ground, run above ground and then return below ground

Black MDPE vs Blue MDPE – what’s the difference? Under BS EN 12201 plain black MDPE is used for above ground drinking water (potable) systems, whereas blue MDPE is used for drinking water systems below ground. Pushfit compression fittings are typically used in this application for sizes 20-63mm, and electrofusion fittings for larger diameters.

What are the different colors of MDPE pipes?

This helps identify if the pipeline could be damaged and should be replaced. This pipe is a multi-layer system which includes a black PE inner core, a protective aluminium layer and an outer layer of PE. The pipe is mainly blue but will have brown vertical lines running along the pipe and an internal black colour.
